Product Description
FEATURES AND BENEFITS
Work with various types of pulse sensors.
Reed switch/Hall sensor/ Cyble sensor/RS485.
Pulse wire connected to the module. Easy to connect.
Accurately count the pulse of the water meter without error.
Specially designed for the water meter industry, accurately identifying pulses.
NFC (Android app) or downlink for configuration purposes.
Split design, can be used underground.
Optional display screen for easier reading.
TECHNICAL SPECIFICATIONS
Pulse types: |
Reed switch/Hall sensor/Cyble sensor/RS485 |
Power supply |
3.6V Lithium battery(8500mAH/4000mAH). |
Battery life |
Up to 6-10 years +reserve |
Transmission interval: |
Standard:daily.5-1440mins |
Operating temperature: |
-10°℃ …+55℃ |
Body material |
Polycarbonate+ABS |
Protection |
IP67/IP68 |
